YIS-503

Yamaha (Japan)

Previous: YIS-303 Next: YIS-503 II
Visits: 12
Name YIS-503 Yamaha
Manufacturer Yamaha (Japan) Type Desktop
Production start (mm-yyyy) 9 - 1984 Production end (mm-yyyy) -
RAM 32Kb + 16Kb VRAM ROM 32Kb
CPU Z80A - 3,579 Mhz
Operating System MSX 1: MSX BASIC v 1.0
Text (Cols x Rows) 40x24, 32x24
Graphics 256x192@16 colors; 32 sprites
Sound 3 sound channels (8 octaves) and a channel of white noise
Storage memory Tape
Serial port Parallel port
Others port Joystick x 2
Original price   Currency original price 0
Units sold
Note Some of the names of the Yamaha computers are followed by a letter (YIS503F or YIS503FB), which indicates, according to some sources, the country of destination(keyboard and type of video-out signal):
  • E: United Kingdom (PAL-I).
  • A: Australia and New Zealand (PAL-B).
  • G: West Germany and most European countrys(PAL-B).
  • S: Scandinavian countrys (SECAM).
  • F: France (SECAM).
  • FB: Belgium (PAL-G).

Configurations Three specials versions of the Yamaha YIS-503 were sell:
  • YIS-503G Graphic System: Is a YIS-503, with two modules: ZGA01 (??) and VC01 (??).
  • YIS-503M Music System: Is a YIS-503, with three modules: YK10 (Small music keyboard), SFG01 (FM Sound Synthetiser) and VC01(??).
  • YIS-503W Word Processing System: Is a YIS-503, with four modules: SKW01 (Kanji Word Processor Unit), PN-101 Printer, CB01 (Printer cable) and VC01(??).
