HB-F1 XDJ

Sony (Japan)

Previous: HB-F1 XD mkII Next: HB-F1 XV
Visits: 14
Name HB-F1 XDJ Sony
Manufacturer Sony (Japan) Type Desktop
Production start (mm-yyyy) 1988 Production end (mm-yyyy) -
RAM 64Kb + 128Kb VRAM ROM 80Kb + 800Kb
CPU Z80A - 3,579 Mhz
Operating System MSX 2+: MSX BASIC v 3.0
Text (Cols x Rows) 80x24, 40x24, 32x24
Graphics 256x192@16 colors - 32 sprites; 512x212/424@19268 colors
Sound 3 sound channels (8 octaves) and a channel of white noise
Storage memory 3,5" floppy disk drive (720Kb)
Serial port Parallel port
Others port
Original price   Currency original price
Units sold
Note
Configurations The HB-F1 XDJ as almost all the MSX2+ has 880 Kb of ROM that are divided of the following way:
  • MSX BASIC v 3.0: 80Kb
  • MSX Disk BASIC v 1.0: 16Kb
  • Music BASIC (FM BIOS): 16Kb
  • JIS 1st & 2nd class Kanji Support: 256Kb
  • MSX-JE: 512Kb
It also has features like a hardware pause key, the Rensha Turbo (a built-in auto-fire system and the repetition speed can be adjusted with a slider).
User juanvm
